Design and Development of a Low-Cost Arduino-Based Pultrusion System with Integrated Heating and Cutting Control for Converting Polyethylene Terephthalate Bottle Waste into 3D Printing Filament

Aristo Bima; Nur Abdillah Siddiq; Panji Dewandaru; Thomas Oka

doi:10.5614/joki.2025.17.2.4

Authors

Aristo Bima Department of Engineering Physics and Nuclear Engineering, Universitas Gadjah Mada, 55281, Yogyakarta, Indonesia
Nur Abdillah Siddiq Department of Engineering Physics and Nuclear Engineering, Universitas Gadjah Mada, 55281, Yogyakarta, Indonesia
Panji Dewandaru Department of Engineering Physics and Nuclear Engineering, Universitas Gadjah Mada, 55281, Yogyakarta, Indonesia
Thomas Oka Department of Engineering Physics and Nuclear Engineering, Universitas Gadjah Mada, 55281, Yogyakarta, Indonesia

Keywords:

Arduino, pultrusion system, PET recycling, 3D printing, additive manufacturing

Abstract

Plastic waste, particularly polyethylene terephthalate (PET) bottles, has emerged as a critical global challenge. Single-use plastic production has continued to increase, while Indonesia generates millions of tons of waste annually, with a significant portion being plastic. To address this issue, this study presents the design of a low-cost Arduino-based pultrusion system for recycling PET bottles into 3D printing filament. Unlike existing open-source solutions that rely on manual or separate processing stages, the proposed system integrates heating, cutting, and cleaning modules into a single automated workflow with real-time control of motor speed and nozzle temperature. Experimental results show that filament tensile strength depends on pultrusion temperature, reaching 67.66 MPa at 195 °C, 62.08 MPa at 185 °C, and 58.64 MPa at 175 °C. Energy analysis indicates that the heater consumed of 0.203 kWh to reach the set-point and 0.509 kWh after one hour, while the pultrusion drive consumed 0.00233 kWh and 0.0257 kWh, respectively. Compared with values reported in prior studies, the tensile strength obtained is within or above typical PET filament ranges. These findings demonstrate that the developed system reduces manual handling, improves efficiency, and produces reliable, energy-efficient filament suitable for additive manufacturing.

References

D. Charles, L. Kimman, and F. Minderoo, Plastic Waste Makers Index. Minderoo Foundation, 2023. Accessed: May 17, 2024 [Online]. Available: https://www.minderoo.org/plastic-waste-makers-index

F. S. Pratiwi, “Mayoritas Sampah di Indonesia dari Sisa Makanan pada 2022 - Dataindonesia.id,” dataindonesia.id. Accessed: May 17, 2024. [Online]. Available: https://dataindonesia.id/varia/detail/mayoritas-sampah-di-indonesia-dari-sisa-makanan-pada-2022.

Kementerian Lingkungan Hidup dan Kehutanan, “SIPSN - Sistem Informasi Pengelolaan Sampah Nasional,” SIPSN. Accessed: May 17, 2024. [Online]. Available: https://sipsn.menlhk.go.id/sipsn/.

R. Geyer, J. R. Jambeck, and K. L. Law, “Production, use, and fate of all plastics ever made,” Sci. Adv., vol. 3, No 7, p. e1700782, Jul. 2017, doi : https://doi.org/10.1126/sciadv.1700782.

M. M. A. Allouzi et al., “Micro (nano) plastic pollution: The ecological influence on soil-plant system and human health,” Sci. Total Environ., vol. 788, p. 147815, Sep. 2021, doi: https://doi.org/10.1016/j.scitotenv.2021.147815.

A. Turner and M. Filella, “Hazardous metal additives in plastics and their environmental impacts,” Environ. Int., vol. 156, p. 106622, Nov. 2021, doi: https:doi.org/10.1016/j.envint.2021.106622.

H. Kristina, A. Christiani, and E. Jobiliong, “The prospects and challenges of plastic bottle waste recycling in Indonesia,” IOP Conf. Ser. Earth Environ. Sci., vol. 195, p. 012027, Dec. 2018, doi: https://doi.org/ 10.1088/1755-1315/195/1/012027.

M. Taufik, G. S. Lubis, and M. Ivanto, “Rancang Bangun Mesin Pultrusion Pembuat Filamen 3D Printing Berbasis Limbah Plastik Botol PET,” JTRAIN J. Teknol. Rekayasa Tek. Mesin, vol. 4, no. 1, pp. 01–08, Dec. 2022. [Online]. Available: https://jurnal.untan.ac.id/index.php/jtm/article/view/60639/75676595655.

I. Tylman and K. Dzierżek, “Filament for a 3D Printer from PET Bottles—Simple Machine,” Int. J. Mech. Eng. Robot. Res., pp. 1386–1392, 2020, doi: https://doi.org/10.18178/ijmerr.9.10.1386-1392.

M. L. Sonjaya, M. Mutmainnah, and M. F. Hidayat, “Construction of plastic waste extruding machine to produce filaments of 3D printing machine,” Int. J. Mech., vol. 16, pp. 82–90, Jul. 2022, doi: https://doi.org/10.46300/9104.2022.16.10.

V. D. Dhopte, G. S. Parate, M. P. Narkhede, and A. Bhongade, “Design and fabrication of PET filament making machine,” Int. J. Res. Appl. Sci. Eng. Technol., vol. 10, no. 4, pp. 1529–1531, Apr. 2022, doi: https://doi.org/10.22214/ijraset.2022.41568.

R. de C. Costa Dias, "Pultrusion of thermoset based profiles—State of the art regarding materials, process set-ups, process modeling, and process simulation," Doctoral thesis, Montanuniversität Leoben, Leoben, Austria, 2020. Accessed: May 17, 2024 [Online]. Available: https://pureadmin.unileoben.ac.at/ws/portalfiles/portal/5919269/AC16111619.pdf

A. K. Singh, B. Saltonstall, B. Patil, N. Hoffmann, M. Doddamani, and N. Gupta, “Additive manufacturing of syntactic foams: Part 2: Specimen printing and mechanical property characterization,” JOM, vol. 70, no. 3, pp. 310–314, Mar. 2018, doi: https://doi.org/10.1007/s11837-017-2731-x.

E. De Avila, J. Eo, J. Kim, and N. P. Kim, “Heat treatment effect on mechanical properties of 3D printed polymers,” MATEC Web Conf., vol. 264, p. 02001, 2019, doi: https://doi.org/10.1051/matecconf/201926402001.

N. Vidakis, M. Petousis, E. Velidakis, M. Liebscher, V. Mechtcherine, and L. Tzounis, “On the strain rate sensitivity of fused filament fabrication (FFF) processed PLA, ABS, PETG, PA6, and PP thermoplastic polymers,” Polymers, vol. 12, no. 12, p. 2924, Dec. 2020, doi: https://doi.org/10.3390/polym12122924.
